Rod ends CF, CF..S Maintenance required





杆端关节轴承
Rod ends CF, CF..S
Maintenance required
-------------------------------------------------------------------------------------------------------------------------------

.-杆端体带有左旋或右旋的内螺纹。
-杆端体挤压成形。
-杆端体表面镀锌。
-英制系列。
-Rod body with right or left-hand female thread.
-Rod body pressed around inner ring.
-Surface of rod body zinc plated.
-In inch dimension series.



-若是左旋螺纹,轴承型号需加“ L ”,例如:CFL10。
-带“* ”的型号均不配油孔或油杯。其余若需配油杯,请用CF..S的代号。
-For left-hand thread, please add suffix " L ", e.g. CFL 10.
-Lubricating hole or grease nipple isn't available for the sizes marked " * ".
When a grease nipple is required for other sizes, please use the sign CF..S.
